A-21
Realtek ALC880 8-Channel Audio
Before you begin using the front panel function, please complete the following steps:
1. Please install the pinheaders of the front panel according to Chapter 2.
2. Select AC97 or Azalia in the BIOS setting (Chapter 3).
3. If you are using Azalia setting, the microphone function on the front panel is
fixed, but the headphone jack will auto detect the device you connect and
pop-up the selection window.
4. If you are using AC97 setting, both microphone and headphone on the front
panel are fixed.
