Serial Port Power Jumper: JCOMP1~3
This jumper species the operation voltage of the COM serial port.
+5V +12V
11
+5V
+12V
11
JCOMP1~2
JCOMP3
LAN Congure Jumper: JLAN1~2
Use this jumper to specify the operation for LAN.
1
JLAN1
(for LAN1)
JLAN2
(for LAN2)
On: Enable security
and the INVM lock.
1
Off: Disable security and
the INVM lock.
(non-secure mode)
JCOMP1 for COM1~2
JCOMP2 for COM3~4
JCOMP3 for COM5~6
