MSI MS-98F6 - Motherboard Layout

1-4
Overview
MS-98F6
Motherboard Layout
Front Audio
Pin Header
Mini-PCIe/mSATA
Slot
Clear CMOS Jumper
AT/ATX Jumper
SO-DIMM Slot
COM Port
Connector
USB 2.0 Pin
Header
LVDS Inverter
Connector
SATA 2.0 Port
GPIO Pin Connector
Back Panel
System Fan
Connector
LVDS
Connector
COM Port Voltage
Jumper
LPC Debug
port Connector
Front Panel
Pin Header
SATA Power
Connector
Amplier Pin
Header
LVDS Power
Jumper
PS/2 Keyboard/Mouse
Connector
Mini-PCIe Slot
LVDS Inverter
Power Jumper
TXE F/W Jumper
LAN1 Jumper
LAN2 Jumper
SMB Bus
Connector
DC-In 12V/19V/24V
Power Connector
