1-3
Overview
MS-98F6
Onboard Pin Headers/ Connectors/ Jumpers
■ 1 x SATA connector
■ 1 x SATA power connector
■ 2 x USB2.0 headers
■ 1 x 8-bit GPIO header
■ 6 x COM port headers
■ 1 x Front panel connector
■ 1 x System Fan connector
■ 1 x LVDS connector
■ 1 x LVDS inverter connector
■ 1 x LPC debug port connector
■ 1 x DC power connector
■ 1 x DIMM socket
■ 1 x Audio connector
■ 1 x Amplier connector
■ 1 x ATX/AT selection jumper
■ 1 x SMBUS connector
■ 1 x PS/2 keyboard/mouse connector
Slot
■ 2 x Mini-PCIe slots (including 1 x mSATA function)
Form Factor
■ Form Factor: 102mm x 146mm
Environmental
■ Operating Temperature: -10
o
C ~ 60
o
C
■ Storage Temperature: -20
o
C ~ 80
o
C
■ Humidity: 10% ~ 90% RH, Non-Condensing
