MSI X99S MPOWER

Chapter 1
1-18
Getting Started
Quad-Channel mode
Installed DIMMs
(6 memory modules)
Diagram

DIMM5, DIMM6, DIMM7
DIMM1
DIMM2

DIMM4
DIMM8
DIMM7
DIMM6
DIMM5
Installed DIMMs
(8 memory modules)
Diagram
DIMM1, DIMM2,

DIMM5, DIMM6,
DIMM7, DIMM8
DIMM1
DIMM2

DIMM4
DIMM8
DIMM7
DIMM6
DIMM5
Important
To ensure system stability for Dual/ Triple/ Quad channel mode, memory modules
must be of the same type, number and density. And for every channel, the odd
󰘰
