CPU
Support
Supports New Intel
®
Core™ i7 Processors Extreme Edition for LGA
Chipset Intel
®
X99 Express Chipset
Memory
Support
8x DDR4 memory slots supporting up to 128GB
Quad channel memory architecture
Expansion
Slots
- 1-way mode: x16/ x0/ x0/ x0
- 2-way mode: x16/ x16/ x0/ x0*, 16/ x8/ x0/ x0**
-
2x PCIe 2.0 x1 slots (PCI_E2,4)
* For the CPU that supports 40 PCIe lanes
** For the CPU that supports 28 PCIe lanes
Multi-GPU
Support
®
CrossFire
TM
Technology*
®
SLI™ Technology
* Supports Windows 7 and Windows 8/ 8.1
Storage Intel
®
X99 Express Chipset
10x SATA 6Gb/s ports (2x ports reserved for SATA Express port)*
- SATA1~6 support RAID 0, RAID 1, RAID 5 and RAID 10
- SATA7~10 ports only support IDE mode and AHCI mode.
- Supports Intel
®
Smart Response Technology (Windows 7/ 8/ 8.1)
1x SATA Express port*
1x M.2 port, supports M.2 SATA 6Gb/s module* or M.2 PCIe
- M.2 port supports 4.2cm/ 6cm/ 8cm length module
- M.2 PCIe module does not support RAID 0, RAID1, RAID 5 and
RAID 10.
* The SATA Express port/ SATA5~6 ports will be unavailable when installing the M.2 SATA
interface module in the M.2 port.
** Intel RST does not support PCIe M.2 SSD with Legacy ROM.
USB Intel
®
X99 Express Chipset
-
- 6x USB 2.0 ports (2 ports on the back panel, 4 ports available
through the internal USB 2.0 connectors)
AsMedia ASM1042AE
-
VIA VL805
-
* Internal JUSB1 connector supports MSI Super Charger.
Audio Realtek
®
ALC1150 Codec
-
- Supports S/PDIF output
LAN 1x Intel I210-AT Gigabit LAN controller
