MTS Systems Temposonics II LDT - Page 51

48
Table 3B
SW 3 Setting Update Time as a Function of Stroke and Recirculation
(Internal Interrogation Only)
Recirculations SW3 Setting (according to stroke length in inches)
1-32 32.1-65 65.1-102 102.1-135 135.1-175 175.1-215 215.1-250 250.1-290 290.1-300
1 0 1 2 3 4 5 6 7 8
2 1 2 3 5 6 7 9 A B
4 1 3 4 6 7 9 B C E
8 1 3 5 6 8 A C E F
16 1 3 5 7 9 B D F F
32 1 3 5 7 9 B E F F
64 1 3 5 7 9 B D F F
127 1 3 5 7 9 B D F F
