3
1.3 Specifications for Temposonics II LDTs over 180 Inches
Below is a list of specifications that pertain to Temposonics II transducers with active stroke lengths of
180 inches (4572 mm) to 300 inches (7620 mm). Special versions of the Analog Output Modules (AOM)
and Digital Interface Boxes (DIB) are required to interface with transducers over 180 inches in length.
Contact an MTS Applications Engineer for details before ordering.
Parameter Specification
Parameter Specifications
Input Voltage: • Maximum: ± 15 Vdc, ± 5% at 100 mA
• Minimum: ± 15 Vdc at 25 mA
(current draw varies with magnet position, maximum draw occurs when magnet is 2 inches
(50.8 mm) from the flange and minimum update time is being used)
Dead Space: 3 in. (76.2 mm)
Cable Length: • Maximum cable length for neuter version transducer (i.e., Temposonics II without an
integrated Personality Module) which requires the use of external interface electronics
(Analog output Module, Digital Interface Box or other signal conditioners) is 250 ft.
• Maximum cable length for Temposonics II transducers with Personality Modules
RPM: 1640 feet (500 meters) using external interrogation
DPM: 300 feet (90 meters) using external interrogation
Magnet Requirement: Part Number: 201554 or 201553 ONLY
