MTU 16V 2000 G63 - 2.3 Main Engine Dimensions

2–04 Main Engine Dimensions
2.3 Main Engine Dimensions
2.3.1 Main engine dimensions
Main engine dimensions
Engine model 12V 2000 Gxy 16V 2000 Gxy 18V 2000 Gxy
Length (A) approx. 2020 mm approx. 2365 mm approx. 2400 mm
Width (B) approx. 1580 mm approx. 1580 mm approx. 1580 mm
Height (C) approx. 1690 mm approx. 1925 mm approx. 1605 mm
M015560/00E 03-05 ©MTU
