8.8.6 Fuel prefilter – Filter element replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Diesel fuel
Filter element
(→ Spare Parts Catalog)
Gasket
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
Replacing filter element
1. Switch off filter to be drained.
1 Left filter cut in
2 Right filter cut in
MS15018/03E 2016-02 | Fuel Filter | 109
TIM-ID: 0000004944 - 006
