MTU 16V2000G65 - 8.7 Fuel System

8.7 Fuel System
8.7.1 Fuel injection line – Pressure pipe neck replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20–100 Nm
F30026582 1
Ratchet adapter
F30027340 1
Adapter
F30006234 1
Open-end socket wrench, 19 mm
F30025897 1
Crowfoot wrench, 19 mm
F30027424 1
Crowfoot box wrench, 22 mm
F30027425 1
Double-head box wrench
F30011450 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Engine oil
Pressure pipe tube
(→ Spare Parts Catalog)
Sealing
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
• Never direct air jet at people.
• Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Close fuel supply line upstream of fuel filter.
2. Drain fuel (→ Page 97).
3. Remove engine governor as necessary (→ Page 142).
4. Remove charge-air manifolds and take off seals (only on engines with air-to-air charge-air cooling).
