Engine with air-cooled intercooler TD
Item Name Monitoring of
1 B7 Lube oil temperature
2 B5 Lube oil pressure
3 B9 Charge-air coolant temperature
4 B10 Charge-air pressure
5 B1 Camshaft speed
6 B13 Crankshaft speed
7 B6 Coolant temperature
8 B33 Fuel temperature
The coolant level sensor F33 is located in the coolant expansion tank at the cooler
22 | General Information | MS15018/03E 2016-02
TIM-ID: 0000022704 - 003
