Area of valve block 12V (without bleeder valve)
Item Type of shielding Comments
1 Shield (B2) Oil return line from valve
2 Shield (B2) Oil supply line
3 Shield (A4) Oil supply to seawater valve, cylin-
der
4 Shield (A4) Oil supply to seawater valve, cylin-
der
5 Shield (A4) Remove shield from bleeder valve
6 Shield (A4) Remove shield from bleeder valve
Area of bleeder valve 16V
MS150119/01E 2016-02 | SOLAS | 71
