Item Type of shielding Comments
1 Shield (A5) Connection on bleeder valve
2 Shield (A5) Connection on bleeder valve
3 Shield (B2) Oil return line from valve
4 Shield (B2) Oil supply line
5 Shield (A4) Oil supply to seawater valve, cylin-
der
6 Shield (A4) Oil supply to seawater valve, cylin-
der
7 Shield (A4) Connection to bleeder valve
8 Shield (A4) Connection to bleeder valve
Free end A-side
Item Type of shielding Comments
1 Shield (A4) Oil supply to cylinder, seawater
shutoff valve
2 Shield (A4) Oil supply to cylinder, seawater
shutoff valve
3 Shield (A5) Oil supply to cylinder, seawater
shutoff valve
4 Shield (A5) Oil supply to cylinder, seawater
shutoff valve
72 | SOLAS | MS150119/01E 2016-02
