Area of coolant distribution housing
Item Type of shielding Comments
1 Shield (A4) From coolant distribution housing
2 Shield (A4) In oil filter
Area of hydraulic cylinder, B-side
Item Type of shielding Comments
1 Shield (A5) Exhaust turbocharger flaps
2 Shield (A5) Exhaust turbocharger flaps
3 Shield (A5) Oil supply for air flap
4 Shield (A5) Oil supply for air flap
5 Shield (A4) Oil supply for air flap
6 Shield (A5) Oil supply for exhaust turbocharg-
er
