6.17 Belt Drive
6.17.1 Drive belt – Condition check
Preconditions
☑ Engine is stopped and starting disabled.
☑ Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt Belt is oily, shows signs of over‐
heating
Replace(→ Page 169)
Drive belt B Cracks on entire circumference
Drive belt C Chunking
166 | Task Description | MS150031/03E 2011-10
TIM-ID: 0000000920 - 008
