7.1.2 Cylinder head cover – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Cylinder head cover – Removal
and installation
Note: Cover the engine beneath the cylinder head
with cloths to collect emerging oil.
1. Remove screws (2).
2. Remove cylinder head cover (1).
3. Clean mating faces.
4. Check condition of profile gasket and re‐
place if required.
5. Position cylinder head cover and screws at positions 1 to 4 and tighten with torque wrench to the prescri‐
bed initial tightening torque.
Name Size Type Lubricant Value/Standard
Screw with twin
collar
M8 Preload torque 10 Nm
