MI.NET MULTI-NETWORK COLLECTOR
36
Installation and Operation Manual
APPENDIX IV: SOLAR INSTALLATION
This document describes only the necessary modifications for using the MNC with a solar-based power source.
Consult the manufacturer’s instructions for assembly, wiring, and grounding the solar array.
• Disconnect AC power to the unit before you begin.
• Switch the AC breaker (labeled “AC”) and the battery breaker (labeled “BATT”) to the OFF position.
SOLAR POWER INSTALLATION NOTES:
• Solar array installation should be performed only by qualified, licensed personnel, and conform to all relevant
regulations
• The solar array should provide AC power, 90-264V, 50 / 60Hz, 100W
• For any solar installation, ensure the MNC battery has been removed. It should be shipped to you without a battery.
Contact Mueller Systems if you have received an MNC with a battery included.
SOLAR BATTERY MONITORING WIRING
The solar array’s Remote Sensor Module (RSM) should be connected to the gateway via General Cable E1004S.41.10. Thread
the four-wire bundle through a protective sheath attached at the Ethernet hole on the bottom right of the collector.
Once connected, the gateway can forward alarms regarding the solar array voltage to the Mi.Host interface.
SOLAR BATTERY ALARMS
Solar Voltage Warning Alarm
Indicates the solar power system is dropping below 12 volts. The alarm is cleared when voltage surpasses 12 volts.
Solar Voltage Critical Alarm
Indicates voltage on the solar power system is dropping below 11.8 volts. The alarm is cleared when voltage is above 11.8V.
