MI.NET MULTI-NETWORK COLLECTOR
6
Installation and Operation Manual
Collector base units are housed in an IP-54 rugged polycarbonate enclosure. Power dissipation ranges from 30 watts (typical) to
100 watts (maximum). The 100W case occurs only when a collector’s internal batteries are being recharged following a power
interruption.
All antenna, network, and power connections to the collector base unit are made at the bottom of the enclosure.
Figure 1: Collector Base Unit and TTU remote antenna assembly – antenna not pictured
