Multiplex Icecore 10 R290 User Manual

10
Section 3
Section 3 – Installation & Commissioning
Unpack the unit from its transportation packing and visually check for any signs of
GDPDJH7KHXQLWVKRXOGEHȴWWHGZLWKDFRUUHFWO\IXVHGDQGZLUHGDPSSOXJȴWWHG
with a 10 amp fuse or alternatively a standard Euro Plug to IEC83: 1975.
For both Ambient and Cold Carbonated appliances in the U.K. a WRAS approved
GRXEOHQRQHUHWXUQYDOYHPXVWEHȴWWHGDVSDUWRIWKHLQVWDOODWLRQRQWKHLQFRPLQJ
mains water connection (for other markets, a none return valve complying with local
ZDWHUUHJXODWLRQVPXVWEHȴWWHGDQGWKHLQVWDOODWLRQVKRXOGRQO\XVHIRRGJUDGHWXELQJ
to interconnect appliances within the system.
Place the unit in a well ventilated, convenient location in the cellar or room where it
is to be sited, as close to the point of dispense as possible, within 2m of an electrical
socket and without obstructions to the condenser (at the front of the unit) or side and
rear panel ventilation slots. Always site the equipment on a dry Horizontal surface of
VXɝFLHQWVL]HWRVXSSRUWWKHXQLWZLWKRXWLWRYHUKDQJLQJ:KHQVLWLQJWKHXQLWHQVXUH
WKDWWKHUHLVVXɝFLHQWVSDFHWRZRUNDURXQGWKHXQLWIRULQVWDOODWLRQDQGFOHDQLQJ$
minimum clearance of 50mm to either side and rear of the unit is recommended.
Unit
Icecore 10 Ambient
Carbonated
Icecore 10 Cold
Carbonated
Height / mm 445mm 535mm
Width / mm 762mm (inc. handles) 770mm (inc. handles)
Depth / mm 440mm (INT) 490 (W\C) 440mm (INT) 490 (W\C)
Weight 52.5Kg’s (Dry) 62 Kg’s (Dry)
