Multiplex Icecore 10 R290 User Manual

38
Section 7
01-3000-XX / 01-3001-XX
HYPER WARWICK
INTEGRAL (01-3000-01)
AMBIENT CARB
HYPER WARWICK
WATER-COOLED (01-3001-01)
AMBIENT CARB
Physical Data
Height 445 mm 445 mm
Width 762mm (inc. handles) 762mm (inc. handles)
Depth 440 mm 440 mm
Operating Weight 77.5 kgs 77.5 kgs
Max Noise dB(A) 70 dBA 70 dBA
Climatic Class 3 kgs 3 kgs
Electrical
Mains Voltage 220-240 VAC, 50 Hz 220-240 VAC, 50 Hz
Run Current 5.1 Amps 5.2 Amps
Fuse Rating 10 Amps 10 Amps
Refrigeration
Compressor Size 12cc 12cc
Duty @ -10ºC Evaporation 846 Watts 846 Watts
Refrigerant R290 (GWP 3 CO2e 0.42Kg) R290 (GWP 3 CO2e 0.42Kg)
Charge 140 grams 140 grams
Controls
Ice Bank Control DFX 1e Electric Control DFX 1e Electric Control
Panel Switches 1 slide switch for soda pump 1 slide switch for soda pump
System protection
Compressor Klixon Klixon
Carbonator Pump Thermal Fuse Thermal Fuse
Recirc Pump Thermal Fuse Thermal Fuse
Coils
Syrup coils 5 x 1.5m 5/16” OD, 316 Stainless steel
Soda coil 11m 3/8” OD, 316 Stainless steel
Pre-chill coil 8m 3/8” OD, 316 Stainless steel
Re-chill coil 4m 3/8” OD, 316 Stainless steel
Still water coil 4.7m 3/8” OD, 316 Stainless steel
6SHFLȴFDWLRQV
6HFWLRQȂ7HFKQLFDO6SHFLȴFDWLRQ
DIAGRAM A (PAGE 8)

Multiplex Icecore 10 R290 Specifications
