13
Section 3
AMBIENT CARBONATED INTEGRAL APPLIANCE CONTROL POSITIONS
01-3000-01 INTEGRAL BACK
CONNECTION DETAILS
REAR CONNECTIONS
POWER TO
CARBONATOR
CARBONATOR
POWER
240V
01-3000-01 INTEGRAL FRONT
SODA ISOLATION SWITCH
SODA PUMP
ISOLATION SWITCH
UP - PUMP OFF
DOWN - PUMP ON
CONTROLLER
PUMP
INDICATOR
(GREEN)
MAINS
POWER INDICATOR
(RED)
MAINS
PUMP
ON
OFF
PUMP
ON
