14
Section 3
AMBIENT CARBONATED WATER COOLED APPLIANCE CONTROL POSITIONS
CARBONATOR
POWER
240V
GLYCOL
POWER
240V
COOLANT
RETURN
COOLANT
FLOW
01-3001-01 WATER COOLED BACK
CONNECTION DETAILS
REAR CONNECTIONS
RE-CIRC
RETURN
RE-CIRC
FLOW
POWER TO
GLYCOL MODULE
POWER TO
CARBONATOR
01-3001-01 WATER COOLED FRONT
SODA ISOLATION SWITCH
SODA PUMP
ISOLATION SWITCH
UP - PUMP OFF
DOWN - PUMP ON
CONTROLLER
MAINS
PUMP
ON
OFF
PUMP
ON
PUMP
INDICATOR
(GREEN)
MAINS
POWER INDICATOR
(RED)
