Multiplex N2-Fusion ND21TS00 User Manual

6 Part Number: 9290312 October/22/2018
General Information Section 1
Specifications
DIMENSIONS
A
C
D
B
E
F
G
H
I
Model A B C D E F G H I
ND21TS00
27.3"
(69 cm)
34.0"
(86 cm)
28.4"
(72 cm)
20.7"
(53 cm)
13.6"
(35 cm)
16.1"
(41 cm)
44.6"
(113 cm)
10.6"
(27 cm)
7.3"
(19 cm)
ND21TS01
ND21TS02
ND21TS03
ND21TS04
ND21RS00 30.75"
(78 cm) *
ND21RS02
* This dimension represents units using 1.25" (3.175 cm) low profile casters, regular casters are 1.25" (3.175 cm) taller.
n
Warning
To avoid instability the installation area must be capable
of supporting the weight of the equipment. Additionally
the equipment must be level side to side and front to
back.
CAPACITY & WEIGHT
Model Max Capacity Volume Weight
ND21TS00
3 - 3 Gallon (11.36L) Coffee Kegs 5.7Ft
3
(161L) 168lbs (76kg)
ND21TS01
ND21TS02
ND21TS03
ND21TS04
ND21RS00
ND21RS02
