Quick Reference Guide
10
RS232 Connection
Plug one end of the serial cable into the RS232 connector on the mo-
dem, and the other end into a serial port connector on your computer,
such as COM1 or COM2.
LINE Connection
Plug one end of the phone cable into the MT2834ZDX’s LINE jack, and
the other end into a phone line wall jack.
Note: The ZDX's LINE jack is not interchangeable with the PHONE
jack. Do not plug the phone into the LINE jack or the line cable into the
PHONE jack.
Note: The Federal Communications Commission (FCC), Industry
Canada, and the British Approvals Board for Telecommunications
(BABT) impose certain restrictions on equipment connected to public
telephone systems. See Appendix A for more information.
PHONE Connection
You may optionally plug a telephone into the ZDX’s PHONE jack. This
jack is provided as a convenience; you may also plug a telephone into a
duplex jack inserted into your wall jack.
