Multitech MultiConnect Cell 100 series - Power Measurements; USB Model Power Draw

PRODUCT OVERVIEW
MultiConnect
®
Cell MTC-MNK1 User Guide 11
Radio
Protocol
Sleep mode
current,
connected to
wireless
Cellular call
box
connection, no
data
Average
measured
current at
maximum
power
Average TX
pulse
amplitude
current
Total inrush
charge, in
Total inrush
charge
duration during
power-up
12 Volts
LTE 836.5
MHz
(Band 5)
7 mA 25 mA 87 mA 132 mA 0.781 mC 7.6 mS
24 Volts
LTE 836.5
MHz
(Band 5)
4 mA 15 mA 56 mA 116 mA 1.24 mC 15.4 mS
USB Model: MTC-MNK1-B03 Power Draw
Radio
Protocol
Sleep mode
current
Cellular
connection
idle, no data
Live
Connection
idle current
Average
current at
Max
Power
Average TX
pulse
amplitude
current
Total inrush
charge
Total
inrush
charge
duration
during
powerup
5 Volts
LTE Band
5
N/A 31 mA N/A 188 mA 340 mA 1.34 mC 8.57 mS
Note:
Tx Pulse: The average peak current during an LTE connection.
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power
Inrush Charge: The total inrush charge at power on.
