Description
Times which have to be set
11.06.2014 27
Time Explanation
Sealing time The film pouch is sealed during this time. The seal-
ing time depends on the material and thickness of
the film pouch.
Recommended value: 1.3 s to 1.5 s
2.6 Technical specifications
Power supply connection
Mains voltage 230 V/50 Hz 110 V/60 Hz
Phases 1/N/PE AC
Nominal power 0.3 kW
Nominal current 5 A 9 A
Maximum mains fuse 16 A 20 A
Maximum short-
circuit current
5 kA
Protection type IP54
Dimensions
Height (a) with open chamber lid 500 mm
Height (a) with closed chamber
lid
275 mm
Width (b) 380 mm
Depth (c) 385 mm
Operating height approx. 250 mm
Effective chamber size (W/H/D) 290 mm/90 mm/205 mm
Sealing length 205 mm
Weight approx. 24 kg
