multivac P100 - Change the Air De-Oiling Element

Maintenance
Change the oil in the vacuum pump
70 11.06.2014
¾ Check the oil level on the oil sight glass.
– There should be a small air bubble at the top of the oil sight
glass.
¾ Turn the screw plug in the fill opening and screw it tight. Turn the
screw plug clockwise.
¾ Wipe off any spilt oil
¾ Close housing, see Section 7.5 "OPEN AND CLOSE THE HOUSING".
¾ Connect the machine to the mains electricity.
¾ Switch on the machine.
¾ Check the oil level after a couple of machine cycles.
7.7 Change the air de-oiling element
¾ Open housing, see Section 7.5 "OPEN AND CLOSE THE HOUSING".
WARNING
Burn hazard!
The surface of the vacuum pump can reach temperatures of over
70 °C during operation.
Touching the vacuum pump can lead to burns.
Before performing any work on the vacuum pump:
¾ Allow the vacuum pump to cool down.
¾ Wear personal protective equipment.
