26992, Rev. 2, 10/10/2013
1
HC-150 and HC-300 Humidistat Field Connections
G
HSP1
Input Plug
HUMIDISTAT
(VICONICS)
P-2
P-1
P-3
G
HSP1 Input Plug
HUMIDISTAT
Regin
P-1
P-2
P-3
DEH
COM
PWR
DEH
1
2
HSP1 Input Plug
HC-150 / 300
Regin Humidistat p/n 90485-xx
All Dashed Wiring by others
All Dashed Wiring by others
