HM3Humidier
3.Nonsolidwallshavetobereinforcedtocarrytheweightoftheunit.Forweightinformation,see
8.1,Dimensionsandweight.
4.Thesafetyoftheinstallationmustalwaysbeveriedbeforeoperation.
NOTE!Theunitmustbepositionedlevelwithin2°inbothdirections.
UnitA(mm/inch)B(mm/inch)
HM32000360/14.2600/23.6
HM35000360/14.2600/23.6
HM310000360/14.21200/47.2
Table4.1Drillingtemplate
4.5Installtheunitontheconsoles
1.Makesurethattheunitisnotconnectedtothepowersupply.
2.NotetheminimumdistancefromthewallinFigure4.1,(mm/inch)togivesufcientaircirculation
andservicespace.
/
13.8
/0.6
/31.5
/15.4
15/ 0.6
Figure4.1Positionontheconsoles
TEN-HM3-B1506Installation8
