HM3Humidier
8Technicalspecication
8.1Dimensionsandweight
HM3size2000500010000
A(mm/inch)550/21.7650/25.6750/29.5
B(mm/inch)350/13.8350/13.8350/13.8
C(mm/inch)775/30.51275/50.21275/50.2
D(mm/inch)730/28.7730/28.71330/52.4
Weightdry(kg/lbs)37/8257/12686/190
Weightwet(kg/lbs)45/10066/146107/236
8.2Waterconsumption
Thetotalwaterconsumptionisthesumofthesupplyofwaterforevaporationandforrinsingaway
impuritiesandwastedeposits:
W
total
=W
usage
+W
drainage
TheformulaforcalculatingthewaterusageforevaporationisW
usage
=1.2*q(△X)/1000,whereqisthe
airowinm
3
/hand△Xistheaddedhumiditying/kg.
ThewaterusedwhendrainingthetankisW
drainage
=Numberofdrainagesperhour*watertanksize*0.33.
Example:
Forasize2000unitwherewewanttoadd2.8g/kgandconstantlyrunonfullspeed.
W
usage
=1.2*2000*2.8/1000=6.7litres/hour
TEN-HM3-B1506Technicalspecication34
