Munters HM3 Humimax User Manual

HM3Humidier
4.7RemoteOn/Offswitchconnection
TouseremotestartwhenthehumidierisinAutomode,anexternalswitchcanbeconnectedtothe
controller.
Figure4.2Connectionofremoteswitch
Connectanormallyopen(NO)switchtoterminalsX3andM,seeFigure4.2.
4.8Humidity/temperaturesensorconnection
CA CA
CA
UTION! UTION!
UTION!
Connectionofthehumiditysensormustbecarriedoutbyapersonwithadequateknowledge.
Followtheinstructionsbelowtoassembleandconnectthehumiditysensorconnectionkittothesensor.
Useathreewiresignalcable.
Connectajumpercablebetween+RHand+T.
-RH
- T
+RH
1
2
3
+T
Figure4.3Connectionofleadsandhumiditysensorconnectionkitassembly
TEN-HM3-B1506Installation10
