HM3Humidier
4.13Watersupplyanddrain
Connectthesuppliedexiblehosetotheunit,andtothemainswatersupplythroughthewaterlterandthe
shut-offvalve.Thevalveisdeliveredtogetherwiththettingfora1/2"pipe.
Theminimumwaterpressureis1bar,maximumpressure8bar.
Themaximumowthroughthesolenoidvalveis3litersperminute.
Thepipesandconnectedequipmentmustbeinstalledinsuchawayastoavoidhigh-pressurepeaksinthe
watersupplypipe.
Theoutletwaterconnectioninnerdiameteris24mm,rubbersleeve.
Thedrainmustextendandterminatewithanindirectconnectiontothesanitarysystembywayofanopen
drain,funneldrain,orxedairgap,allofwhichshallincludeatrappartintheirinstallation.
Makesurethatthedrainhasenoughcapacityfortheoverowprotectiontoworkproperly.
Thetubemustinnopositionbeabovetheoutletconnectiononthehumidier.
CA CA
CA
UTION! UTION!
UTION!
Makesurethatthereisnowaterleakage.
Figure4.5Overowfunnel
4.14Chloridetabletdosing
Ahighconcentrationofdustintheairincreasestheriskforcloggedpadsandwatertank.Infactthe
evaporativehumidierisalsoaveryeffectiveairlter.Problemswithorganicdustandmineralscanbe
reducedbyusinganoptionaldosingsystemwithbromide/chloridetablets.
13InstallationTEN-HM3-B1506
