HM3Humidier
5.2HMILightindications
LEDIndicationFunction
BlinkinggreenStdBy,Start-up/Stopsequence,Override,Fanoverrun,
ConstantgreenRunmode
ConstantorangeAlarm/Immediatestop
Blinking
green/orange
Wiringtestmode
INFO
Blinkingred/orangeCongurationmode
BlinkingredIndicatesactiveandunacknowledgedalarmexists.
ConstantredIndicatesactivealarmsexistbutallalarmshavebeenacknowledged.
ALARM
OffNoactivealarmexists.
Table5.2OverviewofHMILED-lightindications
5.3HMIDisplay
Figure5.1Displayexample,seeTable5.3
TEN-HM3-B1506Operation16
