4.6.2Opensystem
Thespaceisventilatedwithdehumidiedair.
1
Figure4.9Opensystem,dehumidierlocated
outsidetheroom.
1.Dehumidierlocatedoutsidetheroom:
Dryairisemittedintotheroomviaahoseorductconnectedtoa
connectionpiece.
2
Figure4.10Opensystem,dehumidierlocatedintheroom.
2.Dehumidierlocatedintheroom:
Thewetairoutletisconnectedtoahoseandthewetairisemitted
outsidetheroom(outdoors).Thereactivationairandprocessairare
takenintotheunitviahosesorductsandconnectionpieces.Dryair
isemittedintotheroomviaaconnectionpiece.
