MG50&MG90
8Technicalspecication
8.1Dimensionsandservicespace
Figure8.1Dimensions
1.Processairinlet3.Reactivationairinlet
2.Dryairoutlet4.Wetairoutlet
NOTE!ThespecieddimensionsandweightsapplytoboththeMG50andMG90dehumidier.
Width
(A)
Depth
(B)
Height
(C)
Diameter
1
(D)
Diameter
(E)
Service
access
area(F)
Service
access
area(G)
Weight
275mm275mm392mm62,5mm50mm350mm500mm10kg
(1)Adapteravailableasanoptiontoconvertarectangularopeningtoaroundone.
Table8.1Dimensionsandweight
190TGB-1004–N1402Technicalspecication18
