Figure4.2Connectiontoairducts
A.Oriceplateforwetair(includedindelivery)
B.Connectionpiecefordryairoutlet(option)
C.Connectionpieceforairinlet(option)
4.5Mountingtheunitonthewall
TheMGunitcanbemountedonthewallintwodifferentwaysusingawallbracket(optionalequipment),
seeFigure4.3andFigure4.4.Thisenablesoptimizedpositioningofthewetanddryairoutletstomeetany
desiredrequirements.
■Alternative1:Thewetairoutletisplacednearthewallontherightsideoftheunit.
■Alternative2:Thefrontoftheunitispositionedagainstthewallsothatthewetairoutletisfarfromthe
wallontheleftsideoftheunit.
NOTE!Inbothalternative1and2,awoodblock(orsimilar)mustbeplacedbetweenthewallbracketandthe
wall.Thewoodblockisneededtoensurethereissufcientspacefortheairtocirculatearoundtheunitandtomake
itpossibletomountthehumidistatcontact(alternative2).
190TGB-1004–N1402Installation8
