MG50&MG90
Figure4.3Wall-mountedunit,alternative1Figure4.4Wall-mountedunit,alternative2
A.Wallbracket(option)C.Wallpipe(option).Mountedatadownwardangletowardstheoutsideofthe
building.
B.WetairhoseD.Woodblock(depth30mm,width40mm,length350mm)
NOTE!Mountthewallpipewiththethinpipefacingdowntoenablecondensatedrainagethroughthepipe,
seeFigure4.5.
00000
00000
00000
00000
00000
00000
00000
00000
0000
0000
0000
0000
0000
0000
0000
Figure4.5Wallpipe
9Installation190TGB-1004–N1402
