Munters MX2 80 - Main Components MX2 30

Item No.
Description
1.
Reactivation fan
2.
Filter, reactivation air
3. Filter, process air
4.
Steam coil
5.
Cooling f an with filter
6.
Filter, cooling fan
7.
Connector, RJ45
8.
Main powe r switch
9.
Pressure sensor
10.
Process fan
11.
Duct, bypass damper
1)
12. Rotor
13. Drive m otor, rotor
14.
Electrical panel
15.
Control system display
16.
Control panel
17. Pressure sensor
1)
18.
Filter guard
19. Sensor, rotor stop
1)
Option
Table 2.1 Main components, MX² 30
