Munters MX2 80 - Set-up and Test of Steam Heater

Fan coefficient Air flow
(m
3
/h
Dif ferenti al
pressure
(Pa)
Fan speed
(rpm)
Process fan 140 2700 372 3000
MX² 30
Reactivation fan
47 900 367 3000
Process fan
222
3500 249 2400
MX² 35
Reactivation fan
94 1080 132 2550
Process fan
222
4000 325 2770
MX² 40
Reactivation fan
94 1260 180 3000
Process fan
222
5500 614 3000
MX² 55
Reactivation fan
94 1080 132 2550
Process fan 390 6000 237 2330
MX² 60
Reactivation fan
147 1980
181
2930
Process fan 390 8000 421 2820
MX² 80
Reactivation fan
150 2520
282
2940
Process fan 390 9500 593 3000
MX² 95
Reactivation fan
147 1800 150 2540
Table 4.1 Base confi guration settings
4.3 Set-upandtestofsteamheater
1. Mak
e sure that the shut-off valves are closed.
2. Con
nect the reactivation heater to the steam s upply.
3. Op
en the steam supply valves.
4. Ch
eck that correct steam supply pressure is indicated on the manometer.
5
.
C
heck that there are no leaks from the coil or the pipe connections.
6
.
C
heck that the ther mometer is indicating a temperature relevant t o the line pressure.
7. Open the control valve manually, very slowly, to test the condensation evacuation system.
190TEN–108 9–G1412 Commissioning 33
