3-43
Memory switch 07x : Operation
Memory switch 071 :
bit
Initial
Setting
Adjust Usage / Comments
7 0 Factory use only —
6 0 Factory use only —
5 1 Print TCR with the original
page during memory trans-
mission when the result is
error
0 : No
1 : Yes
For easy identification, the first page of a document stored for
memory transmission will print along a TCR when the trans-
mission result is error.
4 0 Factory use only —
3 1 Print TCR with the original
page during memory trans-
mission when the result is
OK
0 : No
1 : Yes
For easy identification, the first page of a document stored for
memory transmission will print along a TCR when the trans-
mission result is OK.
2 0 Print T.30 monitor at com-
munication error
0 : No
1 : Yes
Set this switch to “1” to print out T.30 monitor automatically at
communication error.
1 0 Print T.30 monitor Set this switch to “1” to print out T.30 monitor by each commu-
nication.
0 0 Display modem speed
0 : No
1 : Yes
The transmit/receive speed is displayed in the LCD.
Memory switch 071 — Print TCR with the original page
Switch 3 0 1
Switch 5 0 1 0 1
When Memory transmission was OK, … No No Yes Yes
When Memory transmission was error, … No Yes No Yes
When all broadcast transmissions were OK, … No No Yes Yes
When some broadcast transmissions were error, … No Yes No Yes
Memory switch 072 :
bit
Initial
Setting
Adjust Usage / Comments
7 0 Factory use only —
6 0 Factory use only —
5 0 Factory use only —
4 0 Factory use only —
3 0 Factory use only —
2 0 Factory use only —
1 1 Erase polled document
0 : No
1 : Yes
Determines if a document stored for polling is erased after be-
ing polled.
0 0 Factory use only —
Memory switch 073 ~ 075 : Factory use only
To Next Page
