Murphy HelmView HV1000 User Manual

Section 78 00-02-0604
08-08-07 - 10 -
Engine Type
Single Engine
Configuration
Twin Engine **
Configuration
Crusader
(A) Single Harness Plug A-Port, Stbd (A) Single Harness Plug A-Port, Stbd
Or
(B) Single Harness Plug A-Stbd, Port
Volvo non-EVC
Gas
(C) Dual Harness Plug A&B-Port,
Stbd
(C) Dual Harness Plug A&B-Port, Stbd
Or
(D) Dual Harness Plug A&B-Stbd, Port
Volvo Diesel or Gas
EVC*
(E) Plug D-Port, Stbd (E) Plug D-Port, Stbd
Or
(F) Plug D-Stbd, Port
Cummins
(MerCruiser Diesel)
(C) Dual Harness Plug A&B-Port,
Stbd
(C) Dual Harness Plug A&B-Port, Stbd
Or
(D) Dual Harness Plug A&B-Stbd, Port
Cummins HHP
(C) Dual Harness Plug A&B-Port,
Stbd
(C) Dual Harness Plug A&B-Port, Stbd
Or
(D) Dual Harness Plug A&B-Stbd, Port
Caterpillar
(C) Dual Harness Plug A&B-Port,
Stbd
(C) Dual Harness Plug A&B-Port, Stbd
Or
(D) Dual Harness Plug A&B-Stbd, Port
Yanmar
(E) Plug D-Port, Stbd (E) Plug D-Port, Stbd
Or
(F) Plug D-Stbd, Port
* A NMEA 2000 conversion module is needed. This can be purchased through Volvo Penta (P/N 3840277)
** The difference between A & B, E & F, and C & D is only the orientation of the data on the screen. In a twin
application the engines’ data may appear on the wrong side of the screen. Changing to the secondary option,
A to B, C to D, or E to F, will switch the data to the other side of the display.
5. When the correct setting for ‘Wiring Config’ is displayed, press the Next button to
advance to the ‘Plug Address’ field.
6. With the cursor highlighting the ‘Plug Address’ field, press the Scroll Up or Scroll
Down virtual buttons to scroll through the list of options. These options consist of the
following:
• A:0 B:1 C:2 D:3
• A:1 B:2 C:3 D:4
• A:2 B:3 C:4 D:5
• A:3 B:4 C:5 D:6
• A:4 B:5 C:6 D:7
• A:5 B:6 C:7 D:0
• A:6 B:7 C:0 D:1
• A:7 B:0 C:1 D:2
