Setting MPC-20 to Auto Start on Pressure
1. Access Menu/Application Configuration/Auto Start_Stop Function/Pressure Transducer, and press
[Enter].
2. Complete the parameters that apply (i.e., Maintain Pressure, High/Low Pressure, Start/Stop Pressure,
etc.).
3. Press [Back] twice and access Input_Output/Analog Inputs.
4. Select an Analog Input to modify.
5. Assign the appropriate pressure input for the selected AI.
6. Press the [Menu] key to leave the Menu Setup screens.
Setting MPC-20 to Auto Start on Level
1. Access Menu/Application Configuration/Auto Start_Stop Function/Level Transducer. Press [Enter].
2. Press [Back] once and access Input_Output/Analog Inputs, and select an Analog Input to modify.
3. Assign the appropriate level input for the selected AI.
4. Press the [Menu] key to leave the Menu Setup screens.
Setting MPC-20 to Auto Start on Flow
1. Access Menu/Application Configuration/Auto Start_Stop Function/Flow Transducer. Press [Enter].
2. Press [Back] once and access Input_Output/Analog Inputs, and select an Analog Input to modify.
3. Assign the appropriate flow input for the selected AI.
4. Press the [Menu] key to leave the Menu Setup screens.
Setting MPC-20 to Auto Start on Clock
NOTE: Ensure the correct date and time are established in the System menu prior to
establishing the Auto Start on Clock settings.
1. Access Menu/Start_Stop Timers, and select the first Start/Stop Timer.
2. Select Start Day 1, and then select the appropriate day or Daily.
3. Select Start Time 1, and establish the hour, minute and second to start.
4. Establish the Stop Day and Time as in steps 2-3.
NOTE: The MPC-20 Controller has the ability to establish eight different Start/Stop dates and
times. If desired, repeat the appropriate steps above for subsequent Timers.
Setting MPC-20 to Auto Start on Temperature
1. Access Menu/Application Configuration/Frost Protection/Auto Start_Stop Function/Temperature
Transducer. Press [Enter].
2. Press [Back] once and access Temperature Transducer.
3. Establish a Start and Stop Temperature, and press [Back] twice.
4. Access Input_Output/Analog Inputs, and select an Analog Input.
5. Assign the appropriate temperature input for the selected AI.
6. Press the [Menu] key to leave the Menu Setup screens.
NOTE: If an auto stop condition occurs during the warm-up delay, the controller will enter an
auto stop sequence.
