Murphy ML2000 - Modbus Register Data; Modbus Registers (Engine State & Shutdowns)

Section 40 00-02-0994
2016-06-28 - 41 -
REGISTER #
TYPE
DESCRIPTION
40005
Read Only Current Oil Pressure
40006
Read Only Current Engine Temperature
40007
Read Only
Current Engine State:
#0 ECU Stabilize Delay timing: (1) yes (0) no
#1 Engine Stopped: (1) yes (0) no
#2
Controller in Standby Mode: (1) yes (0) no
#3 Prestart Delay 1 Timing: (1) yes (0) no
#4 Check Safe to Start: (1) yes (0) no
#5 Prestart 2 Delay Timing: (1) yes (0) no
#6 Crank on: (1) yes (0) no
#7 Crank Rest: (1) yes (0) no
#8
False Start Check: (1) yes (0) no
#9 Warm-up Delay Timing: (1) yes (0) no
#10 Line Fill 1 Delay Timing: (1) yes (0) no
#11 Line Fill 2 Delay Timing: (1) yes (0) no
#12 Running Loaded: (1) yes (0) no
#13 Cool-down Delay Timing: (1) yes (0) no
#14
Energize to Stop Delay Timing: (1) yes (0) no
#15 Spindown Delay Timing: (1) yes (0) no
40008
Read Only
Shutdown Status: The following is a description of the bits:
Bit 0 Overspeed SD Status: (1) yes (0) no
Bit 1 Underspeed SD Status: (1) yes (0) no
Bit 2 Overcrank SD Status: (1) yes (0) no
Bit 3
Low Oil Pressure SD Status: (1) yes (0) no
Bit 4 High Engine Temperature SD Status: (1) yes (0) no
Bit 5 Low Fuel SD Status: (1) yes (0) no
Bit 6 Low Discharge Pressure SD Status: (1) yes (0) no
Bit 7 High Discharge Pressure SD Status: (1) yes (0) no
Bit 8 Speed Signal Lost SD Status: (1) yes (0) no
Bit 9
Low Lube Level SD Status: (1) yes (0) no
Bit 10 Fuel Leak SD Status: (1) yes (0) no
Bit 11 Fuel Filter Restriction SD Status: (1) yes (0) no
Bit 12 Air Damper Closed SD Status: (1) yes (0) no
Bit 13 Air Filter Restriction SD Status: (1) yes (0) no
Bit 14 Oil Filter Restriction SD Status: (1) yes (0) no
Bit 15
Remote Stop SD Status: (1) yes (0) no
40009
Read Only
Shutdown Status: The following is a description of the bits:
Bit 0 Coolant Level SD Status: (1) yes (0) no
Bit 1 High Level SD Status: (1) yes (0) no
Bit 2 Low Level SD Status: (1) yes (0) no
