Murr Elektronik MVP12 Series User Manual

Technical Data
User manual 59719_hdb_en_12 30 / 65
4.5.2 Environmental characteristics
4.5.3 Protection
4.5.4 Product reliability
Climatic
Operating temperature -25 °C ... +70 °C
Storage temperature -40 °C ... +85 °C
Installation height Above sea level ≤3000 m
Relative humidity ≤95 %
Mechanical
Vibration test EN 60068 Parts 2-6 5 ... 500 Hz;
const. amplitude 1 mm;
acceleration 15 g
Shock test EN 60068 Parts 2-27 50 g @ 11 ms
Electrical safety
Degree of protection IP68
Protection class III
Degree of pollution 2
Emitted EMC interference
Radio interference field strength EN 61000-6-4 Emission QP: 40 dBμ V/m
@ 30 ... 230 MHzQP: 47
dBμ V/m
@ 230 ... 1000 MHz
EMC immunity
Electrostatic
discharge (housing)
EN 61000-4-2 ±4 kV @ contact
±8 kV @ air
Electromagnetic high-frequency fields
(housing)
EN 61000-4-3 RF field 10 V/m
Rapid transient electric disturbances
(burst)
DC inputs/outputs
EN 61000-4-4 ±2 kV I/O supply
±1 kV data line/
±1 kV I/O line
Magnetic field EN 61000-4-8 30 A/m @ 50 Hz
Conducted interferences,
high-frequency fields
EN 61000-4-6, asymmetric 10 V
Device protection
Overvoltage protection Yes
Overload protection of module supply To be ensured through load circuit monitoring Yes
Reverse polarity protection of module sup-
ply
Yes
Short-circuit protection, sensor supply Electronically
Short-circuit protection, output (DO) Electronically
Protective circuit for input Internal Suppressor diode
Product reliability
MTTF SN 29500 (at 40 °C and rated data) 74 years
