Murr Elektronik MVP12 Series User Manual

Operation
User manual 59719_hdb_en_12 44 / 65
7.2.1.2 Art.-No. 59718, 59818
ISDU
index
DPP
index
Object name Access Length
in bytes
Meaning / default value
Identification
DIO8 Art.-No. 59718 DIO8 Art.-No. 59818
0x0000 0x00 MasterCommand W 1
0x01 MasterCycleTime R/W 1
0x02 MinCycleTime R 1
0x03 M-sequenceCapa-
bility
R 1
0x04 RevisionID R/W 1
0x05 ProcessDataIn R 1
0x06 ProcessDataOut R 1
0x07 VendorID 1 (MSB) R 1 0x012F
0x08 VendorID 2 (MSB) R 1
0x09 DeviceID 1 (octet 2,
MSB)
R/W
1 0x0C
0x0A DeviceID 1 (octet 1,
MSB)
1 0x00
0x0B DeviceID 1 (octet 0,
LSB)
1 0x0B 0x0C
0x0C FunctionID 1 (MSB)
R
1
0x0D FunctionID 2 (LSB) 1
0x0E Reserved R 1
0x0F SystemCommand W 1
0x0002 SystemCommand R 1
0x0003 DataStorageIndex R variable
0x000D ProfileCharacteristic R variable
0x000E PDInputDescriptor R variable
0x000F PDOutputDescriptor R variable
0x0010 VendorName R 64 Murrelektronik GmbH
0x0011 VendorText R 64 www.murrelektronik.com.
0x0012 ProductName R 64 MVP12-P6 DIO8 DIO8
8xM12A IOLB12 B0
MVP12-P6 DIO8 DIO8
8xM12A IOLB12 E0
0x0013 ProductID R 64 59718 59818
0x0014 ProductText R 64 Digital I/O hub
MVP12-P60 - IO-Link Class
B
DIO8 DIO8 8xM12A
Basic Firmware Edition:
2 bytes IN / 2 byte Out
Digital I/O hub
MVP12-P60 - IO-Link Class
B
DIO8 DIO8 8xM12A
Extended Firmware Edition:
4 bytes IN / 2 byte Out
0x0015 SerialNumber R 16 Running serial number
set during production
0x0016 HardwareRevision R 64 e.g. “01.00”
0x0017 FirmwareRevision R 64 e.g. “V.1.00.00”
0x0018 ApplicationSpe-
cificTag
R 16 ... 32 User-specific designation
e.g. “System 3 / Port 4”
0x0019 FunctionTag R 32
0x001A LocationTag R 32
Diagnosis
0x0020 Error Count R 2
