Murr Elektronik MVP12 Series User Manual

Operation
User manual 59719_hdb_en_12 57 / 65
7.3 Diagnostic
7.3.1 Vendor-specific IO-Link events
In addition to the vendor-specific IO-Link events listed here, the standard
events of the IO-Link specification also apply, version see chapter 1.5.3
"Specifications".
Tab. 7-5: IO-Link events
Event
code
Event type Description
0x4000 Error The device shows a temperature fault - overload.
0x4210 Warning The device shows a temperature over-run.
0x4220 Warning The device shows a temperature under-run.
0xFF91 Notification The device requests a data storage upload from the master.
0x5100 Error General power supply fault (US) - below shutdown voltage.
0x5110 Warning Primary sensor supply voltage (US) is over-run.
0x5111 Warning Primary sensor supply voltage (US) is under-run.
0x1830 Warning Secondary sensor supply voltage (UA) is over-run.
0x1831 Warning Secondary sensor supply voltage (UA) is under-run.
0x1832 Error Secondary power supply fault (UA) - below shutdown volt-
age.
0x7710 Error Short-circuit detected on a specific channel.
0x8CA0 Error DIO pin current overload/ shortcircuit - Port 0 Pin 4.
0x8CA1 Error DIO pin current overload/ shortcircuit - Port 0 Pin 2.
0x8CA2 Error DIO pin current overload/ shortcircuit - Port 1 Pin 4.
0x8CA3 Error DIO pin current overload/ shortcircuit - Port 1 Pin 2.
0x8CA4 Error DIO pin current overload/ shortcircuit - Port 2 Pin 4.
0x8CA5 Error DIO pin current overload/ shortcircuit - Port 2 Pin 2.
0x8CA6 Error DIO pin current overload/ shortcircuit - Port 3 Pin 4.
0x8CA7 Error DIO pin current overload/ shortcircuit - Port 3 Pin 2.
0x8CA8 Error DIO pin current overload/ shortcircuit - Port 4 Pin 4.
0x8CA9 Error DIO pin current overload/ shortcircuit - Port 4 Pin 2.
0x8CAA Error DIO pin current overload/ shortcircuit - Port 5 Pin 4.
0x8CAB Error DIO pin current overload/ shortcircuit - Port 5 Pin 2.
0x8CAC Error DIO pin current overload/ shortcircuit - Port 6 Pin 4.
0x8CAD Error DIO pin current overload/ shortcircuit - Port 6 Pin 2.
0x8CAE Error DIO pin current overload/ shortcircuit - Port 7 Pin 4.
0x8CAF Error DIO pin current overload/ shortcircuit - Port 7 Pin 2.
0x8CD0 Error Power pin current overload/ shortcircuit - Port 0 Pin 1.
0x8CD1 Error Power pin current overload/ shortcircuit - Port 1 Pin 1.
0x8CD2 Error Power pin current overload/ shortcircuit - Port 2 Pin 1.
0x8CD3 Error Power pin current overload/ shortcircuit - Port 3 Pin 1.
0x8CD4 Error Power pin current overload/ shortcircuit - Port 4 Pin 1.
0x8CD5 Error Power pin current overload/ shortcircuit - Port 5 Pin 1.
0x8CD6 Error Power pin current overload/ shortcircuit - Port 6 Pin 1.
0x8CD7 Error Power pin current overload/ shortcircuit - Port 7 Pin 1.
