MUSTOOL MT8206 User Manual

6
Buttons
NAME
FUNCTIONS
DIS/AUTO
1. Manually/automatically switching range during DMM measurement;
2. Switching between multimeter/graphical waveform display mode (Hold down);
3.Automatic capture during waveform measurement
REL
1. Showing relative value measurement during DMM measurement;
2. Paging up when reading stored data/waveform;
3. Scaling down the waveform and displaying period during waveform measurement
SELE
1. Selecting DC/AC mode;
2. Measuring frequency/duty cycle;
3. Paging down when reading stored data/waveform;
4. Scaling up waveform and displaying period during waveform measurement
HOLD/DS
1. Saving data/waveform;
2. Reading stored data/waveform (Hold down)

MUSTOOL MT8206 Specifications

General

Brand	MUSTOOL
Model	MT8206
Category	Multimeter
Language	English
