• Read, understand and follow the safety rules and practices outlined in the following context.
• When changing the measurement functions, be sure to remove the test probe from the test point.
Switching measurement functions
Rotate the function switch to select the measurement function and the appropriate range.
The voltage range includes 400mV, 4V, 40V, 400V and 1000V (Note that 750V RMS is available in AC
voltage measurement).
The frequency range is auto range from 5Hz to 5MHz
The capacitance range is auto range from 51.2nF to 100μF, and the large capacitance range is 10mF.
The current range is auto range from 40mA to 10A
The resistance range is auto range from 400Ω to 40MΩ.
Continuity test/diode detection
