5 Self-Diagnosis Mode RJ-901C/RJ-900C Maintenance Manual
5-32
3. Check the printed CW adjustment check patterns for the following points.
(The following shows a case for CW adjustment Low 1)
Print the patterns in the order of A&B / A&C / A&D / A&E / A&F / A&G / A&H.
A
1-1
4A
1A
4A
1A
%
B
Prints repeatedly for
the rest of nozzles
